Product Description

StarTech.com USB-C & USB-A Dock, Hybrid Universal Triple Monitor Laptop Docking Station w/ DisplayPort & HDMI 4K 60Hz, 85W Power Delivery, 6x USB Hub, Ethernet, Audio, USB 3.1 Gen 2 10Gbps - Multi-Monitor Dock (DK31C3HDPDUE) - docking station - USB-C - 3 x HDMI, 3 x DP - GigE

Product Type

Docking station

Docking Interface

USB-C

Video Interfaces

3 x HDMI, 3 x DP

Dimensions (WxDxH)

8.4 cm x 23.3 cm x 3.7 cm

Weight

365 g

Colour

Grey, black

Networking

Gigabit Ethernet

Power

Power adapter 85 Watt AC 100/240 V

Manufacturer Warranty

3-year warranty

General

Product Type

Docking station

Width

8.4 cm

Depth

23.3 cm

Height

3.7 cm

Weight

365 g

Enclosure Colour

Grey, black

Video

Max Resolution Details

4096 x 2160 - 60 Hz

Networking

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion / Connectivity

Interfaces

3 x USB 3.1 Gen 2 - 9 pin USB Type A , 1 x USB-C 3.1 Gen 2 - 24 pin USB-C , 1 x USB-C 3.1 Gen 1 (data only) - 10 pin USB-C , 3 x display / video - 19 pin HDMI Type A , 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 , 3 x display / video - 20 pin DisplayPort , 1 x headphone/microphone combo jack - mini-phone 3.5 mm , 1 x USB-C 3.0 - 24 pin USB-C , 1 x SuperSpeed USB 3.0 - 9 pin USB Type A

Miscellaneous

Cables Included

1 x USB-C/USB-A screw-lock cable - external - 1 m

Features

Security lock slot (cable lock sold separately), USB pass-through connector, UASP transfer protocol, Preboot Execution Environment (PXE) support, full duplex support, up to 3 monitors support, HDR support

Security Slot Type

Kensington security slot

Compliant Standards

FCC, RoHS, USB Battery Charging Specification Rev. 1.2, DisplayPort 1.2, DisplayPort 1.4, UASP (USB Attached SCSI Protocol), USB Power Delivery 3.0

Power

Power Device

Power adapter

Voltage Required

AC 100/240 V

Power Provided

85 Watt

System Requirements

OS Required

Apple MacOS X 10.6, Windows 10

Manufacturer Warranty

Service & Support

Limited warranty - 3 years

Dimensions & Weight (Shipping)

Shipping Width

9 cm

Shipping Depth

25 cm

Shipping Height

17.1 cm

Shipping Weight

1.7 kg

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

50 °C
